Stella SA600 Stand Assist Lift

Heavy Duty Stella Lift SA600E

The SA600E is the 600-lb capacity version of the Stella Stand Assist Lift. This heavy-duty Lift is designed for secure patient transfers and caregiver convenience. Quickly perform all transfers between seated surfaces including toilets and wheelchairs.

The BestStand Bariatric Sit-To-Stand patient lift allows a caregiver to lift and transfer a patient safely with minimum physical effort. For caregiver convenience, the lift can be operated with the included hand pendant/control, or by the soft-touch up/down buttons located on the control box.

With it's 3" dual front casters the SA600 provides smooth maneuverability and low base height of 4.7" for clearance under beds.

This Stand-Up style lift is easier to use than most standard Patient Lifts for transfers to wheelchair, bed or commode.

The Stand-Up style Lift requires the patient to get into a sitting position on the side of the bed. Unlike standard Hoyer/Patient lifts, the Stand-Up Lift cannot lift the patient from a lying position.

The SA600 Series Lift has one of the highest safe working loads in the industry and when used with the unique Bestcare deluxe sling, it provides unparalleled comfort and safety. Extra sling loops on the lift mast allow the Stella Lift to double as a commode lift for increased flexibility.

The Stella style Lift is the ultimate solution for worry free patient transfers between bed, chair or commode.

Designed to significantly reduce manual patient lifting. This lift should be used solely for transferring a patient from one object (beds, bathtubs, toilets, etc.) to another.

Secure and safe for both users and caregivers. Quick and easy access to cleaning and changing. Doubles as a commode lift for additional flexibility.

Slings: Lumbar and underarm pads provide maximum comfort as this sling will not ride up. Use with our Sit-to-Stand Lifts or to replace uncomfortable competitive slings. For those that require some additional initial lift assistance an optional buttocks strap attachment is available. The buttocks strap can be used as a transport sling.

• SA600 Series has 600 lb. safe working load
• Dual 3" front casters provide low base height of 4.7"
• 4" rear casters
• Doubles as a commode lift for additional flexability
• Warning beep for low battery charge and weight capacity levels
• Large ergonomic handles for patient/caregiver comfort and security
• Unique foot pedal base opening for wheelchair/commode access
• Adjustable knee pad unit is wider to fit more patients
• Quick release removable foot platform
• Optional buttock strap for patients requiring additional support
• Low base height provides maximum stability and fits under lower beds

The BestStand Series of sit-to-stand patient lifts provide a solution for patient transfers between bed, chair or commode. The BestStand Bariatric Series of patient lifts reduces injury risk associated with antiquated manual patient lifting practices. The BestStand Lift has set the standard for value and is an option for residential use.

Weight Capacity	Under Bed Clearance	Caster Size (rear/front)	Base Width Open	Base Width Closed	Product Weight	Warranty
600 lbs.	4.5"	4" / 3"dual	38"	26"	129 lbs.	3 Year Limited

Technical Specs - SA600E
Safe Working Load	600 lbs.
Overall Length	40"
Base Height	4.7"
Spreader Bar Height Maximum	70"
Base Closed External Width	26"
Base Open External Width	38"
Base Internal Width Maximum (open)	38"
Boom Internal Width	19"
Hooks Min. Height	35"
Hooks Max. Height	70"
Lifting Mechanism	24 DC Actuator
Battery Charger	AC 110V/220V to DC 24V 1 Amp

Stand Assist Slings - Deluxe
Part #	Size	Patient Tosro Size
Padded Stand Assist:
SL-SA661	Small	Torso 26 - 42"
SL-SA662	Medium	Torso 29 - 48"
SL-SA663	Large	Torso 36 - 60"
SL-SA664	X-Large, Bariatric	Torso 50- 79"
Buttock Strap:
SL-SA669 Buttock Strap, 400-lb
SL-SA669B Buttock Strap, 600-lb, Bariatric
Knee Strap:
SAL1230-KB Stand Assist Knee Strap

Lift frames and spreader bar: 3 years
Actuator/Motor: 2 years
Parts including casters, control box, PCB, pendant, charger: 2 years
Batteries: 1 year
